SFF/H592100
FORST FILTER
8421999090
| Availability: | |
|---|---|
| Quantity: | |
HEPA Panel Air Filter without Clapboard
(1) Best fold shape of filtration media ensures no whirlpool airflow.
(2) High quality fiberglass achieves special filter efficiency and emission.
(3) Withstands high temperature and moisture material construction.
(4) Different fix depth and frame material available on standard filters.
Specification HEPA | |||
Model | Initial Resistance(Pa) | Final resistance(Pa) | Air flow (m3/h) |
203×203×50/65 | 55 | ||
305×305×50/65 | 30 | ||
610×305×50/65 | 300 | ||
610×610×50/65 | 150/100 | 300 | 600 |
610×762×50/65 | 750 | ||
610×915×50/65 | 900 | ||
610×1219×50/65 | 1200 | ||
Test result | ||
Classification | LeakTest | 0.3umHOT.DOP Test: |
Scan Tested | Passed | 99.99％over |
Standard | _ | 99.97％over |
ULPA | |||
Model | Initial Resistance(Pa) | Final resistance(Pa) | Air flow (m3/h) |
203×203×50/65 | 35/55 | ||
305×305×50/65 | 90/130 | ||
610×305×50/65 | 200/300 | ||
610×610×50/65 | 150/100 | 300 | 420/600 |
610×762×50/65 | 530/750 | ||
610×915×50/65 | 640/900 | ||
610×1219×50/65 | 860/1200 | ||
Test result | |||
Test Method | Result | ||
0.12um~0.17um(Particle Counter) | 99.999％over | ||
Leak Test | Passed | ||
Velocity | 0.35m/sec | ||
HEPA Panel Air Filter without Clapboard
(1) Best fold shape of filtration media ensures no whirlpool airflow.
(2) High quality fiberglass achieves special filter efficiency and emission.
(3) Withstands high temperature and moisture material construction.
(4) Different fix depth and frame material available on standard filters.
Specification HEPA | |||
Model | Initial Resistance(Pa) | Final resistance(Pa) | Air flow (m3/h) |
203×203×50/65 | 55 | ||
305×305×50/65 | 30 | ||
610×305×50/65 | 300 | ||
610×610×50/65 | 150/100 | 300 | 600 |
610×762×50/65 | 750 | ||
610×915×50/65 | 900 | ||
610×1219×50/65 | 1200 | ||
Test result | ||
Classification | LeakTest | 0.3umHOT.DOP Test: |
Scan Tested | Passed | 99.99％over |
Standard | _ | 99.97％over |
ULPA | |||
Model | Initial Resistance(Pa) | Final resistance(Pa) | Air flow (m3/h) |
203×203×50/65 | 35/55 | ||
305×305×50/65 | 90/130 | ||
610×305×50/65 | 200/300 | ||
610×610×50/65 | 150/100 | 300 | 420/600 |
610×762×50/65 | 530/750 | ||
610×915×50/65 | 640/900 | ||
610×1219×50/65 | 860/1200 | ||
Test result | |||
Test Method | Result | ||
0.12um~0.17um(Particle Counter) | 99.999％over | ||
Leak Test | Passed | ||
Velocity | 0.35m/sec | ||
