MFS Self-Clean Air Filter Equipment

Share to:
Air power equipment draw-in dust-ladened air, resulting in equipment wear, dust inhalation in wind turbine blade surface scaling, cause the equipment of rotor dynamic balance unbalance accuracy decreased, so that the service life greatly reducing dust, harmful chemical components in will make the equipment rust, corrosion, and air power equipment must be equipped with high precision air filter.
Forst-MSF self-cleaning air filter is similar products at home and abroad on the basis of improved, has reached the international leading level.
  • SFF-MSF Self-Clean Air Filter Equipment
  • FORST FILTER
  • 8421392990
Quantity:

MFS Self-Clean Air Filter Equipment:


Product Descriptions:

Air power equipment draw-in dust-ladened air, resulting in equipment wear, dust inhalation in wind turbine blade surface scaling, cause the equipment of rotor dynamic balance unbalance accuracy decreased, so that the service life greatly reducing dust, harmful chemical components in will make the equipment rust, corrosion, and air power equipment must be equipped with high precision air filter.

Forst-MSF self-cleaning air filter is similar products at home and abroad on the basis of improved, has reached the international leading level.



Features:

(1) The equipment is controlled by the computer to make the air filtering components self-clean. The equipment runs normally without any effect to the filtering efficiency.

(2) Three self-clean modules: timing fixing hand-made.

(3) High efficiency in dust-filtering even in the humble place.

(4) Small lost in resistance.The resistance lost of small filters is less than 250Pa and large filters 600Pa( initializing state ) with the device displaying.

(5) The large fitler is assembled by piling up,which asks for little space.

(6) Installed conveniently.the outlet pipes can be connected at will without the effect of installing place.

(7) Low power consumption,only 100-700W.

(8) Air-compressed volume is 0.1-0.4m3/min(inhaling state) and the pressure is 0.6-0.7MPa.

(9) Light weight,just 2/3 of the cloth-bag oil style.

(10) Long using components,under the common circumstance, the components need to be replaced per 2 years.

(11) As to specific request,our company can design non-standard products to meet needs.


Specification:

Specification

Project

Air volume

m3/min

Initial filtering resistance

(Pa)

Efficiency

μm%

Power(W)

Air consumption

m3/min

Specification(m)

weight(kg)

Length

wildth

height

MFS6

40 m3/min


≥1/99.6


  ≥2/99.8


  ≥3/99.9


  ≥4/100

100


1.6

1.2

2.9

800

MFS12

90 m3/min

< 250

150

0.1

2.1

1.6

3

1000

MFS15

120 m3/min


150


2.5

1.6

3.4

1200

MFS20

160 m3/min


200


2.7

2.1

3.6

1500

MFS30

250 m3/min


200


3.2

2.7

4.1

2300

MFS50

450 m3/min


300

0.2

5

2.7

4.5

4000

MFS60

540 m3/min

< 350

300


5

3

4.5

4800

MFS100

1000 m3/min


450


6.6

2.2

5.9

7000

MFS300

3000 m3/min


450

0.3

10

4.4

6.65

14000

MFS500

5000 m3/min


700


10

6.6

7.25

21000

MFS600

6000 m3/min


700


10.8

6.6

7.45

23000

MFS700

7000 m3/min

< 650

700


10.8

8.8

7.65

27000

MFS800

8000 m3/min


700

0.4

11.6

8.8

7.85

29000

MFS1000

10000 m3/min


700

0.4

12

8.8

8.25

32000


Our products include: Pleated Filter Cartridge Dust Collector System,Cellulose/Polyester+PTFE Air Filter Cartridge,Gas Turbine Air Intake Filter Cartridge,Top/Bottom Pleated Bag Filters,Primary/HEPA/ULPA Panel Air Filter.
