• Imported spun bonded polyester with PTFE membrane, microporou Offers 99.99+% filter efficiency.
• Wide pleat spacing and smooth, hydrophobic PTFE provides excellent particle release
• Excellent resistance to chemical erosion.
• Applicable temperature: 93-135°C.
| Availability: | |
|---|---|
| Quantity: | |
Mainly used in the plasma laser cutting of large-scale steel,shipbuilding,automative, metal processing industry,
welding smoke,thermal spray industry and other special conditions.
Product Features:
1) Imported long fiber polyester filter media,fiber interwoven,evenly distributed.
2) Filter material surface do waterproof ,oil and antistatic processing.
3) Good abrasion resistance,and the capability of withstand airflow pulse inverse blow is better than traditional filter media.
4) Smooth filter media surface,not sticky.
5) Excellent chemical resistance.
6) Electro-galvanized / stainless steel cover, central skeleton.
7) Professional sealing obturator elastic neoprene.
8) Good filter material stiffness,can be repeated washed.
9) Operating temperature ≤ 135 ° C.
10) Greatly increase the effective filtration area.
11) Ensure a low steady differential pressure, improve the circulation of air flow.
12) Small filter cartridge element, easy to install.
13) Especially suitable for large dust concentration industry.
Material (standard) | Material (alternative) | |
Top cap | Aluminium | |
Gasket | EPDM | Silicone |
Inner mesh | Galvanized steel | |
Outside straps | Optional | Glued or ultrasonic welded Weltech straps |
Closed bottom cap | Galvanized steel | Stainless steel |
Filter media | Can be equipped with |
